Used in offshore and industrial applications, TIDAL MARINE™ mooring compensation buoys (CB) are durable and proven in the field for over 25 years.
The integrated heavy duty galvanized connection features a 1-1/4″ connection bar with two freely rotating attachment eyes with load plates that are securely fastened to the buoy hull to prevent rotation and wear.
The float hull module is manufactured using virgin UV-20 stabilized polyethylene that meets rigorous Coast Guard standards for fade, impact, and abrasion resistance.
| GENERAL SPECIFICATIONS | ||
|---|---|---|
| Net Buoyancy | 8,591 lbs | 3,897 kg |
| Total Volume | 155 ft³ | 4,382 L |
| Float Diameter | 59.0 in | 1,500 mm |
| Float Height | 103.0 in | 2,616 mm |
| Overall Length | 118.0 in | 2,997 mm |
| MATERIAL SPECIFICATIONS | ||
| Air Weight | 1,069 lbs | 485 kg |
| Hull Material | Polyethylene | |
| Hull Thickness | 0.25 in | 6.35 mm |
| U.V. Rating | UV-20 | |
| Connection Hardware Material | Heavy Duty Galvanized Steel | |
| Connection Hardware Bar Size | 4.00 in | 102 mm Pipe |
| Mooring & Lifting Eye I.D. | 3.78 in | 89 mm |
| Internal Buoyancy Material | Closed Cell Fused In-Situ EPS Block | |
| Environmental Impact | 100% Recyclable | |
