Key Dimensions
Features & Benefits
Specifications
Diameter
0.42 m
Height
1.14 m
Mass
20 kg
Hull Floatation Volume
0.101 m³
Submergence (Freshwater)
1.39 kg/cm
Max. Mooring Mass (Air Weight)
25 kg
Min. Mooring Mass (Air Weight)
5 kg
Draught (at Min. Mooring Mass)
0.39 m
Reserve Buoyancy (at Maximum Mooring Mass)
30 kg
Features
  • Economical Unlit Marker Buoy
  • Rugged Polyethylene Construction
  • Internal Ballast allows use in Shallow Water
  • 100% Foam Filled with large Handling Eye
  • 100% Recyclable after a long service life
Benefits

Our advanced modelling software can perform dynamic analysis of the interaction between the mooring line and the buoy in normal “operating” conditions to assess and optimize buoy performance. Importantly, this dynamic analysis is also used to assess performance across a range of “survival” conditions.
