TDL-2.60M-SF
Products
DIAMETER
HEIGHT
449 m
MASS
680 kg
SUBMERGENCE
17.6 kg/cm
FOCAL PLANE HEIGHT (MAX)
3.05 m
MINIMUM MOORING WEIGHT
100 kg
MAXIMUM MOORING WEIGHT
500 kg
VISUAL RANGE (AT MAX FP)
2.00 NM
RADAR RANGE
2.00 NM
Features
- Manufactured to stringent Coast Guard requirements Equipment compartment inside Day Mark Tower 316 Stainless steel inserts for Top Marks and Lantern attachment 316 Stainless steel hardware and bolt package Proprietary IALA E108 Compliant colour with UV-20 protection package Foam filled hull floats and structural core prevent sinking on collision Modular construction enables repair of collision damage
- Steel Lifting Arms available in hot-dipped galvanized or 316 stainless steel Proprietary HDPE structural core with anticipated 40 year useful life Conformance to IALA Recommendations Available in Lateral, Cardinal, Isolated Danger, Safe Water and Special Mark
Benefits
- Ideal lower cost option for marking channels Extremely durable modular construction Proprietary HDPE structural core design Designed to withstand harsh Canadian weather conditions Adjustable ballast and mooring configurations Excellent performance in current speed to 4 knots Large Visual Target Area with a 2 NM visible range Superior Radar Detection [229m2 (Max) ; 55m2 (Avg at +/- 3 deg.)] Optional Top Marks and Lantern attachment Storage in upright standing position Ultra-low maintenance and does not require sand-blast and painting
PERFORMANCE SPECIFICATIONS
FOCAL PLANE HEIGHT [MAXIMUM]
3.05 m
DRAUGHT [MINIMUM]
1.44 m
RESERVE BUOYANCY [AT MAX FP]
1,000 kg
MINIMUM MOORING WEIGHT
100 kg
MAXIMUM MOORING WEIGHT
500 kg
VISUAL AREA/SURFACE [AT MAX FP]
2.10 m2
